300x300x300mm 3D printer
L-300 FDM 3D Printer
- Using FDM process principle, it can support industrial-grade printing size up to 300x300x300mm. Its high precision can reach 0.05mm
- Industrial-grade FDM 3D printers are used in a variety of materials: PLA, ABS, PC, Nylon, Carbon Fiber, etc.
- Adopts PLC intelligent control and can print offline. Can continue printing after power failure
Dreambot3D 300x300x300mm 3D printer
The Dreambot3D industrial FDM 300x300x300mm 3D printers are used for prototyping various 3D objects across many industries. The industrial FDM 3D printer works by extruding the melted material through the print nozzle.
The material hardens as it gets layered. The Dreambot3D industrial FDM 300x300x300mm 3D printer is widely used in health, automotive, education, robotics etc. The industrial FDM printer basically brings creativity into reality for you.
Dreambot3D 300x300x300mm 3D printer can deliver effective and efficient results for you. Our industrial 3D printers are available in large sizes to suit large and fast industrial needs. The industrial FDM 3D printer price is affordable and easy to operate.
| Technical parameters | Model | L5-300 |
| Max printing volume | 300x300x400 MM | |
| Printing platform | The platform moves down when printing | |
| Technical principle | FDM fuse manufacturing technology | |
| Print head | High-precision extrusion system (double nozzles can be customized) | |
| Nozzle diameter | 0.2, 0.3, 0.4, 0.6, 0.8MM | |
| Consumable diameter | 1.75MM | |
| Printing materials | PLA, TPU, 95A, water-soluble materials, wooden PLA; customizable ABS, PC, PETG, nylon, carbon fiber, metal filling materials, glass fiber addition materials, etc. (not available for 300 size machines) | |
| Positioning accuracy | X axis 0.0011, Y axis 0.0011, Z axis 0.00125MM | |
| Printing layer thickness | 0.05-0.3MM | |
| Printing speed | 20-150MM | |
| Printing platform | Heating aluminum substrate + black crystal glass platform | |
| Platform temperature | 30-50℃ (30-120℃ optional) | |
| Platform calibration | Automatic pre-calibration leveling | |
| Nozzle temperature | 75-280℃ | |
| Movement noise | 50 dB | |
| Connection method | U disk, SD card (both as a gift) | |
| Screen control | 7 inch full color touch screen (support all languages) | |
| Chassis structure | 3MM thick sheet metal, fully sealed chassis | |
| Filter function | 2 air filter devices | |
| Lighting | LED lighting | |
| Mechanical transmission | Double linkage gantry type machine tool linear navigation | |
| Physical parameters | Dimension | 50x48x73 CM |
| Package Size | 56x53x78 CM | |
| Net weight | 25KG | |
| Gross weight | 45KG |
- Certain 300x300x300mm3D printer materials are known to emit strong odours especially the ABS. As a result of the negative environmental impact of this emission, the best 3D printer for industrial use is equipped with an air filtration system that reduces odour during the printing process, therefore the environment is clean, free from hazardous emissions and noiseless.
- The Dreambot3D 300x300x300mm 3D printer has an automatic memory function such that when power supply is interrupted, printing continues from where it stops. Hence, there is no time or material wastage on printing all over again.
- It happens that during printing, the printing material may be used up; this however does not impact your printing. The automatic recognition system of theindustrial FDM 3D printer will automatically stop and notify you, and you can continue without wasting any material.
- TheDreambot3D 300x300x300mm 3D printer has a high printing efficiency and accuracy of 0.05mm. This means that what you design is exactly what the industrial 3D printer will print.
- The drag chain wiring component of theDreambot3D 300x300x300mm 3D printer prevents wire damage that could result due to high speed over a long time of printing.
- Overheating is impossible when printing due to the two-way cooling unit. The two-way cooling unit ensures that there is no overheating due to repetitive printing.
Test your part
We provide sample testing service, allowing you to check the working quality of our 3D printer before placing an order
6 points why choose us
Automatic resume printing
Full enclose stable frame
The whole machine case is thickened by CNC cutting, with accurate hole position, better assembly stability, and higher positioning accuracy of printer operation.
Allow offline printing
Use U disk or SD card to print without connecting to a computer to print. After starting to print, the data is automatically saved and the U disk or SD card can be removed.
Drag chain wiring design
The wire is installed in the inner casing of the drag chain to effectively ensure that the wire will not be damaged for a long time when the printer moves at high speed.
Precision ball screw
Using the latest Taiwan ball screw, it has higher straightness, lower friction coefficient, better smoothness, higher positioning accuracy and more stability during printing.
Alloy nozzle
Independently developed a unique bullet nozzle with uniform heating and a patented head assembly, so that it can work smoothly without interruption.
More FDM 3D printers
L-500 FDM 3D Printer
The L-500 FDM 3D printer can be used for personal interest printing projects and commercial projects as the moulding size can accommodate 500x500x500mm.
L-600 FDM 3D Printer
The L-600 FDM printer model prints high precision objects size of 600x600x600mm. It is easily operable for home and industrial applications.
L-800 FDM 3D Printer
The L-800 FDM 3D printer is able to print larger objects sizes of up to 800x800x800mm. The model size is ideal for large commercial applications.
